Qhov zoo
HH404 40HP tsheb laij teb yog lub tshuab fais fab sib txuas ua haujlwm rau kev ua liaj ua teb thiab ntau yam - lub hom phiaj ua haujlwm. Nws lub zog tseem ceeb yog nyob rau hauv kev sib koom ua ke lub zog muaj zog (29.4kW) thiab kev tshem tawm hauv av (300mm) nyob rau hauv ib lub thav duab compact, ua rau nws zoo tagnrho rau cov chaw kaw xws li orchards, chaw zov me nyuam, thiab tsev cog khoom. Nrog adjustable wheelbases thiab ntau yam hydraulic xaiv, nws muaj peev xwm ua tau zoo sib xws rau ntau yam kev siv, los ntawm tillage mus rau loading, maximizing koj peev los ntawm unparalleled versatility.
Lub zog muaj zog & Kev ua haujlwm siab:
Lub cav 29.4kW muab lub zog PTO muaj zog tshaj 25kW, ua kom muaj kev ua haujlwm zoo ntawm ntau yam khoom siv nrog tsawg zog poob.
Superior Maneuverability & Clearance:
Lub compact tsim ua ke nrog lub siab 300mm av clearance guarantees tshwj xeeb agility thiab kev ua tau zoo nyob rau hauv orchards thiab ntxhib struts.
Precision Kho & ruaj khov ua haujlwm:
Ob leeg pem hauv ntej thiab nram qab treads yog adjustable, tso cai rau customization rau txawv qoob loo kab widths, uas tiv thaiv cov qoob loo thiab txhim khu kev ua hauj lwm stability.
Ntau yam Hydraulic rau Expanded Function:
Kev xaiv 1 lossis 2-pab pawg hydraulic li qub thiab kev hloov kho kom tsim nyog tau txais kev txhawb nqa yooj yim ntawm ntau yam hydraulic txuas, muab qhov tseem ceeb nthuav dav.
Comprehensive Gearing rau kev ua haujlwm tsis muaj zog:
Nrog 8 rau pem hauv ntej thiab 2 rov qab lub zog, nws yoog rau ntau yam kev xav tau ceev, ua rau ob qho tib si kev ua haujlwm thiab kev ua haujlwm zoo dua.
Khoom Parameters
|
Qauv |
UNIT |
HH404 |
|
|
DIMENSION NTAWM TRACTOR |
HOM |
/ |
DRIVE HOM (4 × 4) |
|
kW |
kW |
29.4 |
|
|
DIMENSION (LxWxH) |
mm |
3420 * 1250 * 2280mm |
|
|
QHOV TSEEB |
mm |
1770 |
|
|
MIN GROUP CLEARANCE |
mm |
300 |
|
|
MINIMUM ua haujlwm MASS |
kg |
1480 |
|
|
NYIAJ |
mm |
Pem Hauv Ntej Tread: 1000 (1000-1300) ADJUSTABLE REAR TREAD: 1000 (1000-1340) ADJUSTABLE |
|
|
MATCHED Hwj chim |
CLUTCH HOM |
/ |
DRY-HOM, SIB QHIA-KEV |
|
Cav |
/ |
National Ⅱ 4 Lub tog raj kheej |
|
|
RATED ceev |
r / min |
2400 |
|
|
Ua hauj lwm PART |
KHOOM |
/ |
8F+2R |
|
PTO HOM |
/ |
6 SPLINE, φ35, Ⅰ HOM |
|
|
PTO Rated zog |
kws |
Ntau dua lossis sib npaug rau 25.0 |
|
|
PTO ceev |
r / min |
540/720 |
|
|
HYDRAULIC SYSTEM |
PEB POINT LINKAGE |
/ |
REAR, Peb-POINT SUSPENSION, CAT1 |
|
HYDRAULIC POOB |
/ |
SIMPLE VALVE (YOG 1-GROUP / 2-GROUP) |
|
|
HYDRAULIC ADJUSTABLE MODE |
/ |
HAUJ LWM HAUJ LWM HAUJ LWM (OPTIONAL FORCED HYDRAULIC SYSTEM) |
|
|
MAX.LIFTING FORCE ntawm FRAME CENTER |
kn |
Ntau dua lossis sib npaug rau 7.1 |
|
|
TIRE HOM |
STANDARED TIRE Size ( Pem hauv ntej / REAR ) |
/ |
6.00-16/9.50-24 |
|
OPTIONAL TIRE (Ⅰ) |
/ |
6.50-16/11.2-24 |
|
Kev koom tes Case: Cov Neeg Ua Teb Lub Suab
Fabkis - Vineyard & Orchard Operator
"Rau ntau tiam neeg, peb tau ua haujlwm hauv thaj av no qhov chaw muaj txiaj ntsig. Peb lub tsheb laij teb qub, dav dav puas vines thiab cov av compacted. HH404 tau tshwm sim. Nws adjustable wheelbase haum zoo kawg nkaus ntawm peb cov kab, thiab lub siab clearance yeej tsis snags cov ceg. Qhov kev xaiv thib ob hydraulic valve tso cai rau kuv los tswj ib sab - mounted machine's tsis siv zog; nws tsuas yog siv lub tshuab ua ntej. peb cov cuab yeej cuab tam."
Canada - Diversified Family Farmer
"Nyob ntawm peb cov liaj teb, peb tsa cov tsiaj nyeg thiab cog qoob loo. Peb xav tau ntau tus neeg ua haujlwm uas yuav tsis tawg lub txhab nyiaj. HH404 lub zog tiag tiag nyob rau hauv nws cov kev sib raug zoo nrog suav tsis txheeb. Peb siv nws nrog rau pem hauv ntej -kawg loader rau kev pub mis rau lub caij ntuj no, ib lub rotary cutter rau pasture nyob rau hauv lub caij ntuj sov, thiab ib tug mini-hay baluster txhais tau tias yooj yim. Kev kho cov nqi rau tsev neeg ua liaj ua teb zoo li peb li, qhov kev ntseeg siab thiab ntau yam yog txhua yam. "
Nyab Laj - Siab -Yield Rice & Zaub Grower
"Nyob rau hauv peb cov dej hauv dej thiab cov nplej mos, ib lub tsheb laij teb tau yooj yim tau daig. HH404 nrog nws cov 4WD thiab cov log tsheb tshwj xeeb tsim kho cov xwm txheej no tau yooj yim. Dab tsi ua rau kuv xav tsis thoob yog qhov yuam- nqa hydraulic system; nws muaj zog txhawb nqa hnyav hnyav xws li rotavator los ntawm cov av sib sib zog nqus. Cov compacting loj ntawm peb cov bunds kuj zoo meej. tau txhawb nqa peb thaj av npaj ntawm lub caij nplej thiab zaub. "
Vim li cas thiaj xaiv Hanhong International?
Ntau tshaj ib lub tsheb laij teb. Peb xa tag nrho Productivity Solutions.
Nyob zoo Cov neeg siv khoom, thaum koj xaiv peb ua koj lub tsheb laij teb xa khoom, koj xaiv ntau tshaj li cov khoom siv xwb; koj tau txais ib lub sijhawm ntev - tus khub tau cog lus rau koj txoj kev vam meej. Nov yog peb cov lus cog tseg rau koj:
Kev cog lus rau cov khoom lag luam zoo: Ua rau cov haujlwm nyuaj tshaj plaws
Kev ntseeg tau & Durability: Peb cov tsheb laij teb yog tsim los rau cov kev xav tau tshaj plaws. Nrog cov cuab yeej siv zog, siab - cov khoom zoo, thiab kev sim nruj, peb ua kom muaj kev ua haujlwm siab thiab ua haujlwm ntev.
Ua Lub Hwj Chim & Tshuab: Peb muab cov tshuab ua haujlwm siab ua raws li cov qauv kev tso tawm thoob ntiaj teb tshiab (xws li Theem V), ua ke nrog cov neeg siv -cov thev naus laus zis (xws li kev xaiv CVT kis tau tus mob), xa cov kev ua tau zoo nrog rau kev siv roj zoo dua thiab kev nplij siab ntawm tus neeg teb xov tooj.
Cov khoom lag luam nthuav dav: Los ntawm cov qauv compact mus rau siab -horsepower workhorses, peb muaj lub tsheb laij teb txoj cai rau txhua qhov kev xav tau, txawm tias koj tswj hwm lub vaj tshwj xeeb lossis kab loj heev - cov qoob loo.
Unbeatable Value: Tsom ntsoov rau koj tus nqi tag nrho ntawm kev muaj tswv
Competitive Initial Investment: Los ntawm optimized supply chains thiab efficiency manufacturing, peb muab cov nqi sib tw heev rau cov khoom uas muaj kev sib piv thiab nta.
Cov Nqi Ua Haujlwm qis dua: Siab- cov tshuab ua haujlwm tau zoo thiab txhim khu kev qha tsim qauv txhais tau tias txo qis kev siv roj thiab txo tus nqi kho, txo koj TCO ntau.
Kev Pabcuam Ntiaj Teb & Kev Pabcuam: Koj Kev Thaj Yeeb ntawm Lub Siab yog Peb qhov tseem ceeb
Rapid Parts Supply: Peb nkag siab tias lub sijhawm poob qis yog poob nyiaj. Peb cov khoom lag luam thoob ntiaj teb muaj txiaj ntsig zoo tau mob siab rau kom tau txais koj cov khoom koj xav tau, ceev ceev.
Kev Pab Txhawb Cov Kws Tshaj Lij: Peb pab pawg kws tshaj lij muab ib qho - ntawm - ib qho kev sab laj, los ntawm kev xaiv tus qauv mus rau kev siv qhov sib xws, xyuas kom koj tau txais cov kev daws teeb meem zoo tshaj plaws rau koj cov kev xav tau tshwj xeeb.
Kev Sib Koom Tes Koj tuaj yeem ntseeg tau
Kev sib txuas lus pob tshab: Peb ua raws li qhib thiab pob tshab tus nqi thiab cov cai uas tsis muaj tus nqi zais.
Flexible Business Solutions: Peb lees paub tias txhua tus neeg siv khoom sib txawv thiab npaj txhij los txiav txim siab them nqi thiab xa khoom kom tau raws li koj xav tau.
Kev cog lus rau Lub Sij Hawm Ntev: Peb tsom mus rau kev tsim kev sib koom tes uas kav ntau xyoo. Koj txoj kev vam meej yog peb txoj kev vam meej.
Kev xaiv peb txhais tau tias xaiv qhov sib xyaw ua ke zoo tshaj plaws ntawm Kev Ntseeg, Tag Nrho Tus Nqi, thiab Kev Pov Hwm Kev Pabcuam. Peb tsis yog muag khoom xwb; peb txhawb koj cov productivity.
Hom Tsheb laij teb
Cov tsheb laij teb tuaj yeem muab faib ua ntau txoj hauv kev, feem ntau raws li lawv qhov kev teeb tsa, kev siv thawj zaug, thiab kev ua haujlwm. Ntawm no yog cov hom:
1. Los ntawm Configuration
Log tsheb laij teb
Nqe lus piav qhia: Hom ntau tshaj plaws, siv cov log tsheb roj hmab. Lawv feem ntau muaj ob lub log tsav tsheb (sab nraub qaum) thiab ob lub kauj tsheb (pem hauv ntej), tab sis plaub-log- tsav qauv kuj muaj dav.
Qhov zoo: Kev kub ceev mus txawv tebchaws, zoo maneuverability, kev thauj mus los siab, haum rau ntau yam kev ua haujlwm thiab kev thauj mus los.
Daim ntawv thov: plowing, seeding, cultivation, cabling.
Crawler Tractors (los yog Track Tractors)
Nqe lus piav qhia: Siv cov lem tas li tsis siv lub log.
Qhov zoo: Tsawg hauv av siab, zoo heev traction thiab tuav, superior kev kawm nyob rau hauv ntub, mos, los yog av nkos tej yam kev mob.
Qhov tsis zoo: Kev mus los qeeb qeeb, tsis zoo rau kev thauj mus los ntev -, tuaj yeem ua rau puas tsuaj rau qhov chaw.
Daim ntawv thov: Heavy-kev ua haujlwm plowing, kev ua haujlwm ntub dej, av sloping, kev tsim kho.
Los ntawm Lub Hom Phiaj
Agricultural tsheb laij teb
Cov tsheb laij teb siv hluav taws xob: Lub tsheb laij teb feem ntau ua liaj ua teb, nruab nrog peb -point hitch thiab PTO, muaj peev xwm ua haujlwm ntau yam kev siv rau txhua yam - nyob ib ncig ntawm kev ua liaj ua teb.
Kab - Cov tsheb laij teb qoob loo: Ua kom muaj kev tshem tawm hauv av siab thiab kho lub log treads kom yooj yim taug kev ntawm kab ntawm cov qoob loo siab (xws li pob kws, paj rwb) rau kev cog qoob loo, txau, thiab fertilizing.
Orchard Tractors: Compact me me with low - cabins profile (lossis tsis muaj cabin) thiab du, rounded bodywork los tiv thaiv kev puas tsuaj rau tsob ntoo txiv hmab txiv ntoo thiab lawv cov ceg.
Muaj tsheb laij teb
Nqe lus piav qhia: Feem ntau hu ua "traction engines" lossis "loaders," lawv feem ntau yog nruab nrog hydraulic kis tau tus mob thiab muaj zog pem hauv ntej- kawg loader.
Daim ntaub ntawv: Kev tsim kho qhov chaw, logistics yards, chaw nres nkoj rau lub ntiaj teb txav, tuav cov khoom, thiab bulldozing.
Garden Tractors (los yog Lawn Tractors)
Nqe lus piav qhia: Cov tsheb laij teb me tsim feem ntau los tswj cov nyom, lub vaj, thiab cov khoom me me.
Daim ntawv thov: Mowing lawns, landscaping, teeb nqa.
Los ntawm Fais fab tso zis (Hespower - HP)
Compact tsheb laij teb (feem ntau qis dua 50 HP)
Mid -Cov tsheb laij teb ntau yam (feem ntau ntawm 50 txog 100 HP)
Siab -Horsepower Tractors (feem ntau ntawm 100 txog 200 HP)
Ultra-High-Horsepower Tractors (feem ntau siab dua 200 HP)
FAQ
Q: Hom kev ua liaj ua teb dab tsi yog 40HP tsheb laij teb zoo tshaj plaws rau?
A: Nws yog ntau yam - rounder rau nruab nrab - cov haujlwm ua haujlwm, zoo kawg nkaus rau kev tswj vaj txiv hmab thiab chaw zov me nyuam, txiav thiab fertilizing ntawm cov tsiaj txhu ua liaj ua teb, plowing thiab rotary tilling ntawm cov liaj teb me, thiab cov khoom siv nrog rau pem hauv ntej - kawg loader. Nws lub zog sib npaug thiab agility zoo tshaj hauv cov chaw kaw.
Q: Cov kev xaiv PTO yog dab tsi, thiab qhov twg kuv xav tau?
A: Peb muab tus qauv 540 rpm thiab kev lag luam 760/1000 rpm PTO. Lub 540 rpm yog rau feem ntau cov khoom siv (piv txwv li, teb tillers). Kev lag luam PTO muab tib lub zog ntawm lub cav qis dua, muab cov roj zoo dua thiab cov suab nrov qis, zoo tagnrho rau cov kev ua haujlwm siab -kev ua tau zoo (piv txwv li, qee cov balers). Xaiv raws li qhov yuav tsum tau muaj ntawm koj cov khoom siv tseem ceeb.
Q: Dab tsi yog qhov hydraulic tso zis system rau, thiab kuv xav tau pes tsawg pawg?
A: Nws yog siv los ua cov khoom siv uas xav tau lub zog hydraulic, xws li pem hauv ntej -kawg loaders thiab rov qab plows. Ib pawg txaus yog tias koj siv ib qho hydraulic siv ib zaug. Koj xav tau ob pawg yog tias koj xav tau los tswj ob txoj haujlwm ywj pheej ib txhij (piv txwv li, lub loader nrog lub grapple). Rau feem ntau cov neeg siv, peb xav kom tsawg kawg ib pab pawg rau yav tom ntej versatility.
Q: Lub tsheb laij teb puas yooj yim los tswj? Puas yog cov khoom siv tau yooj yim?
A: Yog lawm, kev saib xyuas yooj yim yog qhov tseem ceeb ntawm kev tsim qauv. Cov ntsiab lus kev pabcuam niaj hnub (xws li roj lim, lim cua) yooj yim nkag tau. Peb muab cov ncauj lus kom ntxaws saib xyuas thiab lub ntiaj teb qhov chaw muab kev sib txuas los xyuas kom meej tias koj tau txais cov khoom tiag tiag, txo qis sijhawm.
Q: Cov khoom siv puas suav nrog thaum yuav lub tsheb laij teb?
A: Tus qauv hais yog rau lub tsheb laij teb nws tus kheej. Kev siv tau raug xaiv thiab raug nqi sib cais raws li koj qhov kev xav tau tshwj xeeb. Peb cov kws tshaj lij zoo siab los muab cov lus qhia zoo sib xws thiab muab cov kev daws teeb meem tiav nrog rau ob lub tsheb laij teb thiab cov khoom siv.
Kev nqis peev hauv siab - cov tshuab ua liaj ua teb zoo txhais tau tias kev nqis peev rau yav tom ntej ua tiav ua ke.
Hanhong International npaj txhij los koom tes nrog koj, pib nrog lub tsheb laij teb txhim khu kev qha.
